1997 Mitsubishi Eclipse 2.0L L4 Gas

- Designed to increase horsepower
- Washable, reusable, and engineered to last for the life of your vehicle
- Designed to provide high airflow and exceptional filtration
- Engineered to fit easily into your factory air box
- 10-Year/Million Mile Limited Warranty
- Only needs cleaning every 50,000 miles under normal highway driving conditions
- Emissions legal in all 50 States
- Will not void vehicle warranty
Air Filter Shape | Panel |
Filter Material | Cotton Gauze |
Washable | Yes |
Height | 1 in (25 mm) |
Outside Length | 9.313 in (237 mm) |
Outside Width | 7.438 in (189 mm) |
Package Contents | 1 Air Filter |
Package Quantity | 1 |
Warranty | 1,000,000 Miles/10 Year |
Product Style | Panel Air Filter |
Top Style | Open |
Weight | 1 lb (0.4 kg) |
Filter Re-Oiling Amount | 0.99 oz (29 ml) |
Product Box Height | 1.75 in (44 mm) |
Product Box Length | 13.56 in (345 mm) |
Product Box Width | 7.72 in (196 mm) |
Inner Wire | No |
Advanced Moderate Easy
Screwdriver
5-10 Minutes
Installation PDF
Installation Instruction Sheet
- Guaranteed to increase horsepower
- Designed to improve throttle response and engine sound
- Easy to install, usually in 90 minutes or less
- Washable and reusable lifetime air filter
- Lasts up to 100,000 miles before service is required (depending on driving conditions)
- Replaces entire factory air intake system
- K&N Million Mile Limited Warranty®
Estimated Horsepower Gain | 7.74 HP @ 5900 RPM |
Replacement Filter | RF-1019 |
Air Filter Color | Red |
Air Filter Material | Cotton Gauze |
Air Filter Outlet Shape | Round |
Clamps Included | 1 |
Clamp Material | Stainless Steel |
Clamp Style | Regular |
CARB EO Number | D-269-15 |
Couplers Included | None |
Type | Gen I |
Product Style | 57 Series FIPK |
Air Filter Height | 6.75 in (171 mm) |
Street Legal In All US States | Yes |
TUV Approved (Europe) | No |
Weight | 3.5 lb (1.6 kg) |
Product Box Height | 9.25 in (235 mm) |
Product Box Length | 9.13 in (232 mm) |
Product Box Width | 9.13 in (232 mm) |
Mounting Hardware Included | Yes |
Warranty | 1,000,000 Miles/10 Year |
Advanced Moderate Easy
Wrench, Extension, Flat Blade Screwdriver, Allen Wrench
60-90 Minutes
Installation PDF
Installation Instruction Sheet Dyno Chart - 1995 Mitsubishi Eclipse 2.0L - 7.74HP Increase
- Designed to allow high flow rates and a consistent flow of oil to your engine
- Pleated synthetic-blend filtration media removes most harmful contaminants
- Fast and easy Wrench-Off® removal using the welded one-inch hex nut
- High capacity to withstand the service intervals recommended by vehicle manufacturers
- Heavy-duty canister for outstanding durability
- Laboratory tested to ensure excellent capacity, efficiency, and mechanical strength
- Designed to operate with all synthetic, conventional, and blended motor oils
- 1-Year Limited Warranty
Anti Drain Back Valve | Yes |
Bypass Valve | Yes |
Filter Material | High Flow Premium Media |
Gasket Material | Viton Rubber |
Height | 3.75 in (95 mm) |
Outside Diameter | 2.688 in (68 mm) |
PSI Relief Valve | 11-17 |
Removal Nut | Yes |
Style | Canister |
Thread Specification | M20 X 1.5 |
Product Style | Oil Filters |
Weight | 0.6 lb (0.3 kg) |
Product Box Height | 4.13 in (105 mm) |
Product Box Length | 2.88 in (73 mm) |
Product Box Width | 2.81 in (71 mm) |
Removal Nut Size | 1 inch |
Warranty | 1 Year Limited |
Advanced Moderate Easy
20-30 Minutes

- Designed to allow high flow rates and a consistent flow of oil to your engine
- Pleated synthetic-blend filtration media removes most harmful contaminants
- Fast and easy Wrench-Off® removal using the welded one-inch hex nut
- High capacity to withstand the service intervals recommended by vehicle manufacturers
- Heavy-duty canister for outstanding durability
- Laboratory tested to ensure excellent capacity, efficiency, and mechanical strength
- Designed to operate with all synthetic, conventional, and blended motor oils
- 1-Year Limited Warranty
Anti Drain Back Valve | Yes |
Bypass Valve | Yes |
Filter Material | High Flow Premium Media |
Gasket Material | Viton Rubber |
Height | 4 in (102 mm) |
Outside Diameter | 3.656 in (93 mm) |
PSI Relief Valve | 8-11 |
Removal Nut | Yes |
Style | Canister |
Thread Specification | 3/4 In. - 16UNF-2B |
Product Style | Oil Filters |
Weight | 1.2 lb (0.6 kg) |
Product Box Height | 4.5 in (114 mm) |
Product Box Length | 3.88 in (98 mm) |
Product Box Width | 3.88 in (98 mm) |
Removal Nut Size | 1 inch |
Warranty | 1 Year Limited |
Advanced Moderate Easy
20-30 Minutes

- High flow filter designed to improve performance
- Designed for synthetic and conventional oils
- Premium filtration media for increased capacity
- Provides outstanding filtration
Anti Drain Back Valve | Yes |
Bypass Valve | Yes |
Filter Material | High Flow Premium Media |
Gasket Material | Nitrile Rubber |
Height | 3.75 in (95 mm) |
Outside Diameter | 2.688 in (68 mm) |
PSI Relief Valve | 11-17 |
Removal Nut | No |
Style | Canister |
Thread Specification | M20 x 1.5 |
Product Style | Oil Filters |
Weight | 0.6 lb (0.3 kg) |
Product Box Height | 3.5 in (89 mm) |
Product Box Length | 2.9 in (74 mm) |
Product Box Width | 2.9 in (74 mm) |
Warranty | 1 Year Limited |
Advanced Moderate Easy
20-30 Minutes

- High flow filter designed to improve performance
- Designed for synthetic and conventional oils
- Premium filtration media for increased capacity
- Provides outstanding filtration
Anti Drain Back Valve | Yes |
Bypass Valve | Yes |
Filter Material | High Flow Premium Media |
Gasket Material | Nitrile Rubber |
Height | 4 in (102 mm) |
Outside Diameter | 3.656 in (93 mm) |
PSI Relief Valve | 8-11 |
Removal Nut | No |
Style | Canister |
Thread Specification | 3/4 In. - 16UNF-2B |
Product Style | Oil Filters |
Weight | 1.1 lb (0.5 kg) |
Product Box Height | 4.1 in (104 mm) |
Product Box Length | 3.9 in (99 mm) |
Product Box Width | 3.81 in (97 mm) |
Warranty | 1 Year Limited |
Advanced Moderate Easy
20-30 Minutes

- Lasts the lifetime of your vehicle under normal vehicle operating conditions
- Stainless Steel Micro-Screen Filtration
- Reusable Oil Filter
- Billet Aluminum Housing
- Embedded Neodymium Magnets
Anti Drain Back Valve | No |
Bypass Valve | Yes |
Filter Material | Stainless Mesh |
Gasket Material | Viton |
Height | 3.25 in (83 mm) |
Outside Diameter | 2.688 in (68 mm) |
PSI Relief Valve | 16 |
Removal Nut | No |
Style | Canister |
Thread Specification | M20 x 1.5 |
Product Style | Oil Filters |
Weight | 1.2 lb (0.6 kg) |
Product Box Height | 6 in (152 mm) |
Product Box Length | 4 in (102 mm) |
Product Box Width | 4 in (102 mm) |
Warranty | 1 Year Limited |
Advanced Moderate Easy
20-30 Minutes
Installation PDF
Cleaning Instructions
- Lasts the lifetime of your vehicle under normal vehicle operating conditions
- Stainless Steel Micro-Screen Filtration
- Reusable Oil Filter
- Billet Aluminum Housing
- Embedded Neodymium Magnets
Anti Drain Back Valve | No |
Bypass Valve | Yes |
Filter Material | Stainless Mesh |
Gasket Material | Viton Rubber |
Height | 4 in (102 mm) |
Outside Diameter | 3 in (76 mm) |
PSI Relief Valve | 16 |
Removal Nut | No |
Style | Canister |
Thread Specification | 3/4 In. - 16UNF-2B |
Product Style | Oil Filters |
Weight | 1.2 lb (0.5 kg) |
Product Box Height | 6 in (152 mm) |
Product Box Length | 4 in (102 mm) |
Product Box Width | 4 in (102 mm) |
Warranty | 1 Year Limited |
Advanced Moderate Easy
20-30 Minutes
Installation PDF
Cleaning Instructions
